FRAME	SILEX LITE
FORK	MERIDA SILEX CF2
DERAILLEUR REAR	Sram Apex1
SHIFTERS REAR	Sram Apex 1
BRAKE LEVER	Sram Apex 1
BRAKES	Tektro Spyre Mechanical disc
ROTORS	Tektro M160 160mm
CHAINWHEEL	FSA Gossamer 44 teeth
CHAIN	KMC X11-1
HUBS FRONT	VP 173SB 100x12mm width front hub 32 spoke holes 6 bolt
HUBS REAR	VP 273SB 142x12mm width rear hub 32 spoke holes 6 bolt
BOTTOM BRACKETS	FSA PF86 MegaExo
RIM	MERIDA Comp SL 17mm inner width 22mm height
FREEWHEEL	Shimano CS-R7000 11-32 teeth 11 speed
TIRES	Maxxis Razzo 700x35C folding Silkworm
SPOKES	Black stainless
HANDLEBAR STEM	MERIDA Expert CC 31.8mm diameter -5° stem angle
STEM LENGTH	MERIDA Expert CC 31.8mm diameter 5° stem angle
HANDLEBAR	MERIDA Expert GR
HEADSET	MERIDA M2331 Neck
SEAT POST	MERIDA Comp CC 30.9mm diameter 0mm setback
SADDLE	MERIDA Comp SL
SEAT CLAMP	MERIDA Expert
GRIP	MERIDA Expert EC
AXLE FRONT	MERIDA QR48N 12-100
AXLE REAR	MERIDA QR48 12-142
PEDAL	VPE-891
WEIGHT	9.98 kg

	Our proven high-end aluminium (6066) is extremely light and durable. Using triple butted wall thicknesses and hydroforming technology, we can tune the aluminium tubes to give the best possible stiffness to weight ratio.
	Tubes are inserted into negative moulds and a hot emulsion of water and oil is forced through at pressure, enabling them to be formed into complex shapes.
	Using a tapered head tube with 1 1/8" bearings in the top and 1 1/4" or 1 1/2" in the bottom creates superb stiffness and precise, confidence inspiring steering.
	Sometimes called ‘double pass welding’, a second pass over the weld gives a clean organic look to the frame. At first glance, you will be convinced it is carbon.
	Cables are routed through the frame, entering and exiting through smooth sockets. The bike looks neat, whilst the cables are protected from moisture and dirt.
	Cables, housings and brake hoses are clamped under tension to prevent rattling when the trails or roads get rough. All inlets are completely interchangeable to deal with Di2, hydraulic hoses, brake cable and gear cable housings etc.
	‘F-Mount’ equipped bikes have integrated fittings for mud guards (some bikes require model specific mud guards), making fitting fast and simple.
	‘C-Mount’ equipped bikes have the fixing points for a rear rack already integrated (some bikes require model specific rear rack), making fitting fast, simple and reliable.
	Carbon forks provide superb vibration damping and precise steering. All road bikes feature a full carbon fork; the steerer and fork blades are all made of carbon.
	A 142 mm wide 12 mm rear axle fixed directly into the frame increases rear end stiffness whilst simplifying wheel removal and replacement.
	Selected front forks use a 100 mm wide through axle 12 mm in diameter to increase lateral stiffness.
	A forged aluminium component under the front and/or rear caliper allowing heat to dissipate through CNC-milled cooling fins. Tests show that temperatures are reduced by around 35 % and cooling times are shortened, optimising the performance of the brake.

FRAME SIZE	XS	S	M	L	XL
TIRE SIZES	28"	28"	28"	28"	28"
FRAME SIZE CM	44	47	50	53	56
ST SEAT TUBE [MM]	440	470	500	530	560
TT TOP TUBE [MM]	548	554	579	600	620
CS CHAIN STAY LENGTH [MM]	430	430	430	430	430
HTA HEAD TUBE ANGLE [°]	71	71	71	71	71
STA SEAT TUBE ANGLE [°]	74	74	74	74	74
BD BOTTOM BRACKED DROP [MM]	75	75	75	75	75
HT HEAD TUBE [MM]	160	180	200	220	240
FL FORK LENGTH [MM]	397	397	397	397	397
R REACH [MM]	380	380	400	415	430
S STACK [MM]	587	606	625	644	663
WB WHEEL BASE [MM]	1027	1034	1060	1082	1103
SH STAND OVER HEIGHT [MM]	715	742	770	797	825
BODY HEIGHT CM	< 167	165 - 177	173 - 185	181 - 192	> 188

MERIDA GRAVEL

FRAME SIZE BODY HEIGHT

XS < 167 cm

S 165 - 177 cm

M 173 - 185 cm

L 181 - 192 cm

XL > 188 cm
